adhesive weight - Typ 397, 60 g, steel, silver

Product information "adhesive weight - Typ 397, 60 g, steel, silver"
Steel adhesive weight bolt from Perfect Equipment with 5 g-division. Equipped with protruding protective film on the adhesive strip for easy handling. Width: 19 mm height: 3.8 mm (incl. adhesive tape) Segmentation: 12x5 g (60 g Packaging units: 100 Pieces Made in Germany

Why should you balance tyres at all?

At a speed of 100 km/h the centrifugal force of a 10 g unbalance acts like the force of a sledge hammer. This makes wheels without balancing weights a danger: Without adhesive weights on steel and aluminium rims, wheel suspensions and bearings are subjected to greater stress. Missing balancing weights on steel and aluminium rims can also lead to noticeable vibrations at the steering wheel and in the interior. In addition, non-existent adhesive bars result in increased brake and tyre wear.

Assembly of adhesive weights:

Basically the rim surface must be free of grease, silicone, dust and dry before mounting the adhesive weights. The processing temperature of the adhesive weights must not fall below 10 °C and the surface for attachment to the rim must not exceed a maximum bevel of 15°C; from the hub direction.

Then select the required grammage of the adhesive weights and, if necessary, separate the balancing weights from the adhesive bar or the adhesive weight roll. Then carefully bend the adhesive weight slightly smaller than the rim radius and adjust to the rim radius.

Then you can remove the protective foil of the adhesive weights or balancing weights and stick the weight in the middle of the intended place. Press the weight firmly from the middle to the outer ends - the pressure on the adhesive weights must be at least 10 N/cm².
Technical Information
"adhesive weight - Typ 397, 60 g, steel, silver"
Configuration: Latch
Balancingweight Tape Fingerlift:
Width mm: 19
Dimensions unit: CM
Length mm: 150
Manufacturer article number: 3397-0601-210
Type adhesive tape: Standard
Type balance weight: Adhesive weight
Balance weight grammage gr: 60
Customs tariff number: 87087099
Unit to packaging type quantity:
Height mm: 3
Box Packaging Quantity: 100
